Description
STUDIO CUE LIGHTS
Table Cue Lights
Manufactured from polished solid ash, black ash or mahogany, to match our acoustic tables. Fitted with high quality brass lamp holder accepting 15 watt BC pigmy lamp. Lamps can be replaced simply by unscrewing lens cap. Units are supplied as standard with domed red lenses - green, blue, amber or clear lenses available as optional extras. 7.5 metres of mains cable is fitted. Supplied complete with 240 volt lamp.
|
Dimensions: | approx 150mm dia × 102mm (inc lens). |
Floor Cue Lights
Top section turned from solid aluminium, black anodised. Fitted with lamp holder and bulb as in table cue light. Mounted on non-telescopic lightweight stand with folding legs. Cable runs down centre of stand, and extends 7 metres from stand. Earth connection to both stand and lampholder.
Supplied as standard with domed green lens - red, blue, amber or clear lenses available as optional extras. Total height from floor level approx. 1.2 metres.
This product is ideal for outside broadcasts when used in conjunction with the Canford Opto-Switcher, stock code 42-682.
Wall Mounted Cue Lights
These single and dual cue light units use the same lamp holder and lens as our table and floor cue lights, and are supplied complete with opal 15w bulbs fitted. Coloured lenses are not supplied and should be ordered separately according to requirements. The fittings are housed in a two-tone grey polycarbonate enclosure, which has rear entry for cable access and snap-on over. Bulbs are changed by unscrewing lens only.
|
Dimensions: | 187mm (h) × 108mm (w) × 97mm (d), excluding lampholder bezel or lens. |
Lampholders
This has a black plastic bezel and brass BC lampholder, designed to take 15 watt “pigmy” type lamps, and comes complete with locking ring for panel mounting. Supplied without lens, which should be ordered separately. Panel cutout diameter 54mm, depth (measured from front of panel) 60mm, maximum panel depth 35mm. Suitable Q-Max sheet metal punch is 55-695.
Manufactured by Canford.
