Description
K&M GOOSENECK TABLE BASE
Two designs of bases for direct mounting of goosenecks, featuring XLR 3- or 5-pin female input connectors on the top and XLR 3- or 5-pin male output connectors on the rear, by K & M (Konig & Meyer).
2937 Series
A beautifully designed, compact, zinc die-cast base, available with a variety of combinations of connectors, switching and indication. Note: microphone phantom power (24 - 48V) must be present for indicators to function.
Dimensions: 130mm diameter, 35mm height. Weight 0.5 kg
29373
Input 3-pin female. Output 5-pin male. Noiseless grey press-to-talk latching switch and two LEDs indicating phantom power present (amber) and mic on (red).
29374
Input 3-pin female. Output 5-pin male. Noiseless black press-to-talk switch and two LEDs indicating phantom power present (amber) and mic on (red).
29375
Input 3-pin female. Output 3-pin male. Noiseless grey press-to-talk latching switch and two LEDs indicating phantom power present (amber) and mic on (red).
29376
Input 3-pin female. Output 3-pin male. Without press-to-talk switch.
29377
Input 3-pin female. Output 3-pin male. Noiseless black press-to-talk switch and two LEDs indicating phantom power present (amber) and mic on (red).
29378
Input 5-pin female. Output 5-pin male. Without press-to-talk switch.
2939 Series
Weighing in at nearly 3kg, these substantial cast iron bases should provide a stable mounting for even the heaviest gooseneck combinations, for applications such as paging microphones, talkback systems or sound reinforcement. The bases are fashioned in a sturdy, workmanlike, style which will be appropriate in reception desk, office and industrial environments where suitability for purpose and longevity are of prime importance. The black powder coated casting has a horizontally mounted XLR-style female socket on its upper face, and a removable plate, suitable for fitting switches, indicators, controls or connectors (such as headphone sockets), with access to space for additional user supplied circuitry. Rubber feet avoid slippage.
Two types are available, type 29390 is fitted with a rear mounted 3-pole XLR style male connector, fully wired to the upper female connector. Type 29394 is fitted with an LED illuminated single pole "non-latching" changeover switch, mounted on the removable plate, and a 5 pole XLR style male connector on the rear. This version is supplied unwired. Overall dimensions are 160 × 150 × 51mm, Weight is 2.4kg.
Both models are also available complete with a Canford gooseneck microphone 250XB (stock code 53-182), at a special package price. For other suitable goosenecks see “Goosenecks” and “Gooseneck microphones”.
