Description
RANE GRAPHIC EQUALISERS
All Rane graphic equalisers have constant Q filters (narrow) which prevent interaction between filters and so do not change bandwidth when filters are boosted or cut. Front panel controls also include an overall gain control for each channel as well as overload indicators. 6.35mm A-gauge jacks and XLRs are used on each of the inputs and outputs, which are all electronically balanced. Unbalanced sources may also be connected. An optional security cover SC1.7 is available.
ME15B
A 1U rack-mounting dual channel 15 band (2/3 octave) graphic equaliser with ±12dB gain per band.
ME30B
A 1U rack-mounting single channel 30 band (1/3 octave) graphic equaliser with ±12dB gain per band.
Technical Specification:
|
Signal to noise ratio: | 92dB (ref. +4dBu, sliders centred) |
|
Channel separation (ME15): | 70dB, (20–20000Hz unity gain) |
|
THD @1kHz: | 0.009% (ref. +5dBu 20-20000Hz) |
|
Maximum output level: | +21dB |
|
Equaliser bands (ME15): | (15) 2/3-octave, ISO spacing, 25–16000Hz |
|
Equaliser bands | |
|
(ME30): | (30) 1/3-octave, ISO spacing, 25–20000Hz |
|
Slider type: | 20mm travel,centre detent |
|
Equaliser range: | ±12dB or ±6dB, switch selectable |
|
Overall gain range: | Off to ±6dB (slides centred) |
|
Inputs: | Electronically balanced 20k ohms, A gauge 3-pole 6.35mm jack |
|
Outputs: | Balanced 200 ohms/unbalanced 100 ohms. 3 pin XLR and 6.35mm 3 pole A-gauge jacks. |
|
Bypass: | Passive (switched) |
|
Power supply: | 190–250V AC, 50Hz (mains cable included) |
|
Dimensions: | 483(w) × 44(h) × 133(d)mm, weight 2.3kg |
