Description
DENON CD PLAYERS
The Denon range of rack-mounting CD players extends from simple, easy to operate models to designs intended for use in professional applications, with balanced connections and interfacing to event control systems. All have digital, as well as analogue outputs.
DN-C110P - 3U - IR Control, MP3
A CD and CD-R player, IR remote controlled, mp3 playback compatible, designed for easy operation in applications such as background music, education, leisure or corporate A/V. Playback functions include Programme, Repeat and Random, whith an optical output included to integrate with a suitably equipped amplifier. A 100mm display shows track, time, and status information, whilst other controls on the front panel include: Press buttons for Play/Pause, Track Skip forwards and backwards and Stop plus the Time select and Display functions. The remote control duplicates the front panel features and also allows the playback modes to be selected. Captive power cable.
Response: 2Hz - 20kHz, +/-3dB. Noise: -105dB. Distortion: 0.003% THD. Outputs: Analogue, 2.0V peak, 10kohms, RCA (phono). Digital: TOSLINK optical. Dimensions: 3U rack-mounting, 279mm depth. Weight: 4.0kg. Power consumption: 230VAC. 13W.
Included accessories: User manual, rackmount kit, infra red remote control, two AAA batteries, stereo RCA (phono) cable.
DN-C200P - 3U - Five Disc Changer - CD/CD-R, MP3, WMA
Providing sequential random, programmed and repeat playback for up to five CD/CD-R MP3, or WMA audio discs, this has similar features on the front panel to the DN-C100P, other than a carousel loading tray and buttons for random play and 'Disc Skip'. The IR remote control duplicates the front-panel controls and adds additional functions such as: Track number select and A-B repeat by 0-9 numeric key entry. On the rear, outputs are analogue and digital coaxial by three RCA (phono) connectors as well as TOS-link optical. Two 3.5mm jack sockets are provided for additional remote control, duplicating the functions of the infra red remote supplied.
Response: 2–20kHz, +/-3dB. Noise: -108dB. Distortion: 0.003% THD. Power source: 230VAC, 15W. Dimensions: 3U rack-mounting, 400mm depth. Weight: 6.3kg.
Included accessories: User manual, rackmount kit, infra red remote control, two AAA batteries, stereo RCA (phono) cable, IEC C7 power cable.
DN-C615 - 2U - CD, CD-R, CD-RW, MP3
This 2U rack-mounting model has a cascade feature to enable multiple players to be connected for continuous playback. Play modes include Repeat, Random and Programmable, with track selection enabled by the 0-9 numeric key pad. CD Text is supported. With +/-12% pitch control it may be controlled with an infra red or wired remote control. Output connections are two RCA (phono) for analogue audio and the digital output is SPDIF coaxial. The power cable is captive.
D/A conversion: 8x oversampling. Response 20Hz-20kHz +/-3dB. Distortion: 0.007%THD. Noise: -107dB, A weighted. Channel separation: 90dB. Output: 2.0V RMS at 0dB disc level. Power source: 230V AC, 13W. Dimensions: 2U rack-mounting, 280mm depth. Weight: 4.7kg.
Included accessories: User manual, RCA(phono) lead.
DN-C635 - 2U - CD, CD-R, CD-RW, MP3 - XLR out
The varispeed features of this player allow +/-12% pitch control in 0.1% increments from the 75mm fader on the front panel, and can be locked out to avoid accidental adjustment. Other professional features include: Balanced outputs with variable level controls, and interfacing for AMX or Crestron automation systems, plus a port with contact closures controlling play functions including fader start. Three programmable presets allow storage of parameters such as: Enabling, disabling or locking any or all of the remote or local control functions as the application requires, type of EOM (track end indication), playback speed, auto cue level, power on, finish and sleep modes. Applications could range from professional broadcast to club music DJ sytems.
Large buttons offer Cue, Play, Pause and Stop controls on the front panel. There is a 6.35mm stereo headphone socket with associtated volume control, a rotary, press-to-select control for track skip operations. The 'Programme In' button selects remote operation mode, the 'Title' mode allows full display of track information from either CD or MP3 discs. A 110mm display shows all status and track information and enables menu control and CD Text display. On the rear are two XLR otputs with their associated, inset, level adjustment controls and two RCA (phono) for analogue audio as well as SPDIF coaxial digital outputs. There are 9-pin and 25-pin female D-Sub connectors for RS232C or RS422A serial and general purpose control interfaces. Two additional pairs of RCA sockets provide 'Cascade' in, out and the 'Synchronised Record' function for Denon devices. The power cable is captive.
D/A conversion: 8x oversampling. Response: 5Hz-20kHz +/-3dB. Distortion: 0.004% THD. Noise: -104dB. Channel separation: 90dB. Power source: 230V AC. 15 W. Dimensions: 2U rack-mounting, 250mm depth. Weight: 4.7kg.
Included accessories: User manual, RCA(phono) lead.
DN-C640 - CD, DVD, DVD+RW and Network Audio Player
This versatile design has an embedded web server offering a graphical interface to networked computers. It is also capable of play-back from networked resources, and uploading of audio material. Audio interfacing is comprehensive, including balanced analogue and digital outputs. For a more complete description, see 'Denon Network, DVD, And CD Players - Audio'.
