20-921 CANFORD IN-LINE ATTENUATOR 20dB, 600 ohms

each 1+
Price £ 19.62
Qty:

Images may be provided for illustrative purposes only, please consult the product description for exact details.

CANFORD IN-LINE ATTENUATOR 20dB, 600 ohms
CANFORD IN-LINE ATTENUATOR 20dB, 600 ohms

Description

IN-LINE ATTENUATORS

A range of in-line, fixed value, balanced attenuators, with XLR female and XLR male 3 pin connectors. Attenuation value and impedance engraved on barrel.

Nominal impedance 200 ohms: Attenuation accuracy ± 0.2dB when used with source and load impedances of approx 150-200 ohms. Nominal impedance 600 ohms: Attenuation accuracy ± 0.2dB when used with source and load impedances of approx. 600 ohms.

NOTE: 60dB 600ohm type may also be used to derive mic level signals from most line sources to avoid excessive loading; however the choice will depend on the output impedance of the source to be attenuated.

Manufactured by Canford.
