Connecting to PC, Mac and iOS devices, these may be suitable for mobile applications, use in schools, community and internet radio stations.
AT2020USBi
The AT2020USBi is a cardioid condenser microphone with digital output via Micro-HDMI socket, intended for home-studio recording, voiceover work and podcasting
The microphone incorporates a 'high-quality' A/D converter which provides high-resolution audio at up to 24bit/96kHz sample rate. A thumb-wheel provides gain control for simple adjustment of the input level.
The AT2020USBi takes BUS power from the connected USB device. It requires 5V DC via USB, or 3.3V DC when connected via Lightning socket. A coloured LED indicates power status.
Included accessories: Pivoting stand mount for 5/8 inch, 27 threaded stands, 5/8 inch-27 to 3/8 inch-16 threaded adapter, soft protective pouch, tripod desk stand, 1.5m USB cable, 1.5m Lightning cable.
| Element: |
Fixed-charge back plate, permanently polarised condenser |
| Polar pattern: |
Cardioid |
| Response: |
20 - 20,000Hz |
| Power requirements: |
USB (5V DC); Lightning (3.3V DC) |
| Bit depth: |
24 bit |
| Sample rate: |
Up to 96 kHz |
| Controls: |
Mic gain control via thumb wheel |
| Weight: |
374g |
| Dimensions: |
164 x 52 mm (height x max. body diameter) |
| Output connector: |
Micro HDMI |
| Requirements: |
Macintosh: MAC OS 10.6 and above |
| |
Windows: Windows 7 and above |
| |
iOS: iOS 7.02 and above (requires Lightning connection) |
