MUXLAB VIDEO EXTENDERS - Over IP

30 items

MuxLab video extenders are available in point to point, point to multi-point, and multi-point to multi-point configurations, facilitating the transfer of data from compatible equipment over IP for distances up to 120m. They are typically used for live video, broadcast, and studio to studio production and data transfer.

3G Video Extenders


500756 - 3G-SDI, 120m reach

Transmitter (500756-TX) and receiver (500756-RX) 3G-SDI extender over IP components with RS232. Together they offer 'easy extension and distribution of broadcast quality SDI, HD-SDI or 3G-SDI video with embedded audio over local area networks'. It may also be used in point-to-point mode, without a network switch.

Used as a point-to-point link, without a network switch and in conjunction with each other, they will provide transmission of 3G SDI video over a length of up to 120 metres of Cat5E or Cat6 cable. When used with a network switch, whereby point to multipoint, and multipoint to multipoint becomes possible, the maximum reach is set by the design of the network. If it is a Cat5E wired network, then each segment of cable can be up to 100 metres, so a simple network with a single switch has a maximum reach of 200 metres, if the switch can be placed exactly in the middle. The introduction of extra switches and perhaps fibre cabling will increase the available extension.

Both the 500756-TX transmitter and 500756-RX receiver support PoE and have LEDs for 'Link' and 'Power' on the front panel, as well as four miniature (DIP) switches for setting the address of the device. On the rear they have a female BNC for the video connection, a 3.5mm jack socket for on IR emitter or IR detector, a socket for power and an RJ45 connector for the network connection. A 9-pin D-sub connector provides the RS232 connection in each case, with a male version on the receiver and female on the transmitter.

Signals supported: SD-SDI, HD-SDI, 3G-SDI protocol, IR pass-through and RS232 bi-directional communication. Note that 3G-SDI level B is not fully supported. Embedded audio support. Bandwidth: 2.94Gbps.

Power source: Both units may be powered by power over Ethernet where available, or 5V DC from two optional AC adapters. Power drawn: 2.9W transmitter, 1.8W receiver. Dimensions: 112 x 76 x 25mm, each unit. Weight; 0.5kg. Operating temperature: 0 to 40 degrees C.

Optional power supply: 500993

HDMI Video Extenders

500752 - HDMI 1.3, 100m reach

A transmitter (500752-TX), and receiver (500752-RX) that allow HDMI equipment to be connected up to 100m at 1080p by way of single Cat5e/6 unshielded twisted pair cable. Normal operation is in a point-to-point configuration however point-to-multipoint and multipoint-to-multipoint is possible by connecting several transmitters and receivers to the same Ethernet network. Is is important for the Ethernet switch to have Gigabit ports, DHCP server capability, and IGMP communication protocol for these additional setups to function correctly.

The transmitter (500752-TX) and receiver (500752-RX) also support PoE (PD) if used with a PoE (PSE) Ethernet Switch.

Dimensions: 205 x 150 x 55 (HxWxL)mm. Weight: 0.54kg.


500754 - HDMI, 120m reach

A transmitter (500754-TX) and receiver (500754-RX) combination that allows the user to create a video wall from a HDMI source. Depending on available bandwidth multiple receivers, one per display, can be linked with a maximum distance of 100m over Cat5e/6 cable. This can be extended to 120m when a single transmitter and single receiver are used with a network switch.

Supporting PoE, these HDMI 1.3 extenders have ‘virtually lossless video’ with a single frame of latency, along with 1080p resolution compatibility. RS232 and infrared remote control are usable, along with control via networked device, such as mobile or tablet when using in conjunction with 500811 ProDigital Network Controller.

Dimensions: 112 x 76 x 25 (WxDxH)mm. Weight: 0.5kg.


500759 - HDMI, 100m reach

These units have been designed to allow the extension of 4K, 30Hz or 1080p, 60Hz signal to create a video wall with only bandwidth hampering the number of receivers the user can implement.

On the rear panel, a 5V DC power supply input is positioned next to a HDMI output (input on transmitter), RS232 connection, 3.5mm female jack connector for 'Sensor IR' ('Emitter IR' on transmitter), 3.5mm female jack socket for audio out (audio in on transmitter) and RJ45 for LAN connection and POE power.

Dimensions: 112 x 129 x 25 (WxDxH) mm. Weight: 0.68kg.


500759-TX-HLO - HDMI, 100m reach, loop out

The same in principle as the 500759-TX however also features a HDMI loop output to enable local display. Also supports up to 4K at 30Hz, and 1080p and 60Hz.

Dimensions: 112 x 129 x 25 (WxDxH) mm. Weight: 0.70kg

Optional power supply: 500993


500759-TX-DANTE - HDMI/Dante, 100m reach

The same in principle as the 500759-TX however also allows the connection of Dante audio equipment.

Dimensions: 112 x 144 x 25 (WxDxH) mm. Weight: 0.77kg.

Optional power supply: 500993


500762 - HDMI, 100m reach

These units transmit and receive 4K/60Hz video streams over IP H.254/H.265 to a distance of up to 100m. The transmitter (500762-TX) supports up to 1080p, 60Hz whilst the receiver (500762-RX) up-scales the 1080p to 4K, 60Hz, as well as supporting video wall and multi-view configurations. A benefit of the low bandwidth requirement of this equipment means audio and video data can be conveyed via local network, WiFi, and internet distribution. Multicast is supported along with RTSP, RTMP, HLS, FLV and TS.

Transmitter connectivity is the same as 500758-TX, and receiver connectivity is the same as 500758-RX with the addition of USB3.0 and S/PDIF and TosLink output located on the front panel.

Dimensions: 111 x 129 x 25 (WxDxH) mm. Weight: 0.4kg.


500763-TX - HDMI, 100m reach

Compatible with the 500762-RX, 500763-TX allows a HDMI source of up to 4K/30 resolution to be conveyed up to 100m via Cat5e/6 UTP cable.

Dimensions: 111 x 111 x 25 (WxDxH) mm. Weight: 0.4kg.


500764-TX - HDMI, 100m reach

Compatible with the 500762-RX, 500764-TX allows a HDMI source of up to 4K/60 resolution to be conveyed up to 100m via Cat5e/6 UTP cable.

Dimensions: 154 x 111 x 25 (WxDxH) mm. Weight: 0.5kg.


500774 - HDMI/ST2110, 400m reach

This transmitter (500774-TX-MM), and receiver (500774-RX-MM) have been designed to allow uncompressed HDMI video up to 4K/60, and SMPTE ST-2110 within a broadcast environment. Whilst having the ability to extend the signal up to 400m via multimode OM4 fibre, 500774 also gives the user the ability to insert audio and extract audio on the transmitter and receiver respectively.

500774 supports point-to-point, point-to-multipoint, and multipoint-to-multipoint configurations, along with 2x 10G Ethernet ports for communications, and a single 1G Switch port for compatible network adapters. SMPTE ST-2110 can be manager through its web interface and an NMOS system via a RestAPI.

Dimensions: 111 x 175 x 25 (WxDxH) mm. Weight: 0.7kg.

Note: Although standard Ethernet technology can be used, and technically could be used in a network with other traffic, Muxlab do not recommend this for some of the above products, due to the throughput of traffic generated by the extenders.

HDMI KVM Video Extenders


500760 - KVM HDMI, 4K/60, 100m reach

A transmitter (500760-TX-KVM) and receiver (500760-RX-KVM) combination designed for KVM and Smart Whiteboard applications. Supporting HDMI resolutions up to 4K/60 (4:4:4), the transmission can carry up to 100m in distance over Cat5e/6 UTP cable, and supports audio insert (on the transmitter) and audio extraction (on the receiver).

Compatible with 10Gig Ethernet switches, the extender also supports RS232 and infrared remote control, along with control via networked device, such as mobile or tablet when using in conjunction with 500811 ProDigital Network Controller.

Dimensions: 195 x 132 x 33 (WxDxH) mm. Weight: 1.42kg.


500770 - KVM HDMI and USB, 1080p, 100m reach

These products allow the transmission or reception of HDMI 1.4 and USB data up to a distance of 100m via Cat5e/6 in a point to point or point to multipoint configuration. It supports HDMI source up to 1920x1200 and 1080p, 60Hz. Both transmitter (500770-TX) and receiver (500770-RX) support POE when used with Ethernet switch.

Both transmitter and receiver have a 4-channel DIP switch to set up the device ID on the front panel, along with a yellow LED to signify link status, and LED to show power on. Also on the front panel of the transmitter is a USB type B socket; the receiver has four USB type-A connectors. On the rear panel, a 5V DC power supply input is positioned next to a HDMI output (input on transmitter), 3.5mm female jack socket for audio out (audio in on transmitter) and RJ45 for LAN connection and POE power.

Dimensions: 112 x 129 x 25 (WxDxH) mm. Weight: 0.68kg.


500771 - KVM DVI and USB, 1080p, 100m reach

These products are the same as 500770-RX and 500770-TX except that in place of the HDMI connections, DVI in (500771-TX) and out (500771-RX) are positioned on the rear panel.

Dimensions: 112 x 129 x 25 (WxDxH) mm. Weight: 0.68kg.


500772 - KVM HDMI and USB, UHD-4K, 100m reach

500772-TX and 500772-RX allows the extensions of USB and ultra-HD 4K HDMI signals over IP up to a distance of 100m. Supporting 4K at 30Hz, 4:4:4; and 4K at 60Hz, 4:2:0; multipoint to point or point to multipoint configurations are possible. 500772-RX includes a 4-port USB hub, and powering is via PoE or optional 500993 universal power supply.

Dimensions: 112 x 129 x 25 (WxDxH) mm. Weight: 0.68kg


500800 - KVM HDMI and USB, 4K/60, 100m reach

500800-TX and 500800-RX allows the extensions of USB and 4K/60 HDMI signals over IP up to a distance of 100m. 500800 supports signals up to 4K at 60Hz, 4:4:4; in a multipoint to point or point to multipoint configuration. 500800-RX includes a 4-port USB hub, and powering is via PoE or optional 500993 universal power supply.

Dimensions: 162 x 140 x 25 (WxDxH) mm. Weight: 0.68kg


500850 - KVM HDMI and USB, 4K/30, 100m reach

500850-TX and 500850-RX allow KVM HDMI signal extension over IP up to 100m. Supports HDMI up to 4K/30Hz (4:4:4) and 4K/60Hz (4:2:0) via Cat5e/6 cable in multiple point-to-point and point-to-multipoint configurations. The transmitter (500850-TX) and receiver (500850-RX) both support PoE (PD) if used with a PoE (PSE) Ethernet Switch.

The transmitter terminates to a computer server/workstation via an HDMI & USB port, the receiver terminates to an HDMI display and up to 4 USB devices such as a keyboard, mouse, printer, drawing pad, storage device, etc., via a 4 port USB hub. In addition, the transmitter has an HDMI loop out for connecting a local TV and the receiver features a HDMI input for connecting a local video source.

Dimensions: 68.9 x 21.7 (HxW)mm. Weight: 0.68kg

Power Supplies (optional)


500992 5VDC, 1.2A

Compatible with 500752, 500753, and 500754. Includes US, EU, and UK compatible connection blades.


500993 5VDC, 2.6A

Compatible with 500755, 500755-AMP-TX, 500756, 500757, 500758, and 500759. Includes US, EU, and UK compatible connection blades.

  Description Price £
ex. VAT
Add to basket
Delivery
MUXLAB 500752-RX VIDEO EXTENDER Receiver, HDMI 1.3 over IP, 1080p, PoE, 100m reach Stock code: 89-1016
No longer manufactured. Please contact Technical Support for alternatives.
MUXLAB 500752-TX VIDEO EXTENDER Transmitter, HDMI 1.3 over IP, 1080p, PoE, 100m reach Stock code: 89-1015
No longer manufactured. Please contact Technical Support for alternatives.
MUXLAB 500754-RX VIDEO EXTENDER Receiver, HDMI over IP, PoE, HD, 120m reach Stock code: 89-0952
2 in stock Need more?
£338.70
Clearance
£230.00
MUXLAB 500754-TX VIDEO EXTENDER Transmitter, HDMI over IP, PoE, HD, 120m reach Stock code: 89-0953
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£338.70
MUXLAB 500756-RX VIDEO EXTENDER Receiver, 3G-SDI over IP, PoE, RS232, 120m reach Stock code: 89-0927
Ordered on demand, cancellations may incur charges, available in 1‑2 weeks. Need it sooner? Call us
£414.00
MUXLAB 500756-TX VIDEO EXTENDER Transmitter, 3G-SDI over IP, PoE, RS232, 120m reach Stock code: 89-0928
Ordered on demand, cancellations may incur charges, available in 1‑2 weeks. Need it sooner? Call us
£414.00
MUXLAB 500759-RX VIDEO EXTENDER Receiver, video wall, 4K over IP, PoE, 100m reach Stock code: 89-0943
Ordered on demand, cancellations may incur charges, available in 1‑2 weeks. Need it sooner? Call us
£474.20
MUXLAB 500759-TX VIDEO EXTENDER Transmitter, video wall, 4K over IP, 100m reach Stock code: 89-0944
Ordered on demand, cancellations may incur charges, available in 1‑2 weeks. Need it sooner? Call us
£474.20
MUXLAB 500759-TX-HLO VIDEO EXTENDER Transmitter, HDMI over IP, PoE, UHD-4K, loop out Stock code: 89-1010
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£493.80
MUXLAB 500759-TX-DANTE VIDEO EXTENDER Transmitter, HDMI/Dante over IP, PoE, UHD-4K, 100m reach Stock code: 89-0968
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£715.00
MUXLAB 500760-RX-KVM VIDEO EXTENDER Receiver, HDMI over IP, 4K/60, 100m reach Stock code: 89-0954
Ordered on demand, cancellations may incur charges, available in 1‑2 weeks. Need it sooner? Call us
£1,200.00
MUXLAB 500760-TX-KVM VIDEO EXTENDER Transmitter, HDMI over IP, 4K/60, 100m reach Stock code: 89-0955
Ordered on demand, cancellations may incur charges, available in 1‑2 weeks. Need it sooner? Call us
£1,200.00
MUXLAB 500762-RX VIDEO EXTENDER Receiver, HDMI over IP, PoE, 100m reach Stock code: 89-0945
No longer manufactured. Please contact Technical Support for alternatives.
MUXLAB 500762-TX VIDEO EXTENDER Transmitter, HDMI over IP, PoE, 100m reach Stock code: 89-0946
Ordered on demand, cancellations may incur charges, available in 1‑2 weeks. Need it sooner? Call us
£585.00
MUXLAB 500763-TX VIDEO EXTENDER Transmitter, HDMI over IP, H.264/265, PoE, 4K/30, 100m reach Stock code: 89-0956
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£745.00
MUXLAB 500764-TX VIDEO EXTENDER Transmitter, HDMI over IP, H.264/265, PoE, 4K/60, 100m reach Stock code: 89-0957
Ordered on demand, available in 2‑3 weeks. Need it sooner? Call us
£2,100.00
MUXLAB 500770-RX VIDEO EXTENDER Receiver, KVM HDMI over IP, PoE, 100m reach Stock code: 89-0947
No longer manufactured. Please contact Technical Support for alternatives.
MUXLAB 500770-TX VIDEO EXTENDER Transmitter, KVM HDMI over IP, PoE, 100m reach Stock code: 89-0948
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£359.80
MUXLAB 500771-RX VIDEO EXTENDER Receiver, KVM DVI over IP, PoE, 100m reach Stock code: 89-0949
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£414.00
MUXLAB 500771-TX VIDEO EXTENDER Transmitter, KVM DVI over IP, PoE, 100m reach Stock code: 89-0951
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£414.00
MUXLAB 500774-RX-MM VIDEO EXTENDER Receiver, HDMI/ST2110 over IP, uncompressed, MM, 400m reach Stock code: 89-0958
Ordered on demand, cancellations may incur charges, available in 1‑2 weeks. Need it sooner? Call us
£1,650.00
MUXLAB 500774-TX-MM VIDEO EXTENDER Transmitter, HDMI/ST2110 over IP, uncompressed, MM, 400m reach Stock code: 89-0959
Ordered on demand, cancellations may incur charges, available in 1‑2 weeks. Need it sooner? Call us
£1,650.00
MUXLAB 500772-TX VIDEO EXTENDER Transmitter, KVM HDMI over IP, PoE, UHD-4K, 100m reach Stock code: 89-1008
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£459.20
MUXLAB 500772-RX VIDEO EXTENDER Receiver, KVM HDMI over IP, PoE, UHD-4K, 100m reach Stock code: 89-1009
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£459.20
MUXLAB 500800-TX VIDEO EXTENDER Transmitter, KVM HDMI over IP, PoE, 4K/60, 100m reach Stock code: 89-1006
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£677.00
MUXLAB 500800-RX VIDEO EXTENDER Receiver, KVM HDMI over IP, PoE, 4K/60, 100m reach Stock code: 89-1007
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£677.00
MUXLAB 500850-TX VIDEO EXTENDER Transmitter, KVM HDMI over IP, 4K/30, PoE, 100m reach Stock code: 89-1013
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£526.00
MUXLAB 500850-RX VIDEO EXTENDER Receiver, KVM HDMI over IP, 4K/30, PoE, 100m reach Stock code: 89-1014
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£526.00
MUXLAB 500992 POWER SUPPLY Interchangeable US/UK/EU, locking connector, 5VDC/1.2A Stock code: 89-0998
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£10.53
MUXLAB 500993 POWER SUPPLY Interchangeable US/UK/EU, locking connector, 5VDC/2.6A Stock code: 89-0999
Ordered on demand, available in 1‑2 weeks. Need it sooner? Call us
£13.55
